The APA05 Wi-Fi Signal
Booster is a highly efficient and compact unit designed to
increase
the performance and range of any 2.4 GHz wireless device. This includes
Bluetooth, P2P, P2MP,
802.11b, 802.11b+, 802.11g, 802.11n, and 802.11b+g access points and
wireless routers.
The APA05 extends signal range, and in certain conditions, can double
the range of these
wireless devices. This eliminates the use of an additional radio with
its associated data line, power
outlet, signal interference, and setup headaches. The APA05 is the fast
and easy way to extend your
signal range in any environment.
|
Perfect
For...
- WIRELESS HOTSPOT
- BRIDGE LINK
- BETWEEN NETWORKS
- WIRELESS LOCAL
- AREA NETWORK
Key Features
- Works with Access Points & Routers
- Increases Signal Distance
- Increases Throughput
- Quick & Easy Installation
- Immediate Results
- No Programming Required
- Complete with Power Supply
Applications
- WLAN 802.11b & 802.11g & 802.11n
- DSSS on the ISM Band
- CBluetooth
|
|
| Model |
APA05 |
| Frequency Band |
2.4GHz ~ 2.5GHz |
| Signal Type |
DSSS |
| TR Switch
Time |
< 1?sec |
| Weight |
20g |
| Size - L*W*H |
155mm * 21.6mm * |
| RF
Connector Type |
90° RP-SMA Male |
| Antenna
Connector Type r |
RP-SMA Female
|
| Tx Linear
output Power |
500 mW / +27 dBm max. @
11g
800 mW / + 29dBm max @ 11b |
| Diagnosis
LED |
Pwr@Green,
Tx@Red,
Rx@Amber |
| DC Supply
Voltage |
6.0V, 1A |
| Supply
Voltager |
6.0V |
| Rx Input
power |
-10 dBm |
| Tx Input
power |
+20 dBm |
| Operating
Temperature |
-0 ~ +50 °C |
| Storage
Temperature |
-40 ~ +90 °C |
|
 |
